9mm Isocheck Screedcheck Underscreed XL9 Impact Improvement Mat - 1.2m x 50m roll

9mm Isocheck Screedcheck Underscreed XL9 system is designed to be placed directly below the screed within a masonry structural floor to isolate the screed from the structural sub floor, and provides sufficient impact absorption. The Isocheck Underscreed XL9 system features a 9mm closed cell non-cross linked foam layer. When installed correctly, the Isocheck Underscreed XL9 system will enable compliance with Approved Document E 2003 and subsequent amendments in 2004, 2010, 2013 and 2015.

• Underscored impact improvement mat,
• Easy to handle and install,
• Closed cells prevents water absorption,
• Excellent acoustic performance,
• High resistance to compression and creeping,

• Designed to be placed directly below the screed within a masonry structural floor.

• The floor surface should be swept free of any loose debris that may damage or bridge the system.
• Isoocheck Screedcheck XL9 can be rolled up the wall or lapped and taped to a perimeter flanking strip.
• Either option should allow a minimum 50mm to protrude above the intended FFL of the screed.
• Adjoining roll edges should be butt-jointed jointed and sealed with a minimum 100mm wide jointing tape.
• Services that penetrate the screed should be isolated by wrapping with Underscreed which again would be taped.
• When trafficking the floor take care not to perform any unnecessary actions that may cause any of the taped joints to be forced apart.
